Specifications:
Engine:
HP Category- 57 HP
Engine Rated RPM- 2100 RPM
No Of Cylinder- 4
Air Filter- Dry Type with Clog Indicator
Cooling System- Forced Circulation of Coolant
Transmission (Gearbox):
Clutch Type- Dual Diaphragm Type
Transmission Type- Partial Synchromesh
Gear Lever Position- Side Shift
Speed Minimum to Maximum- 1.71 – 33.5 km/h
Reverse Speed Minimum to Maximum- 1.63 – 32.0 km/h
Forward Gears- 15
Reverse Gears- 15
Rear Axle- Bull Gear Reduction
Brakes:
Brake Type- Mechanical, Oil Immersed Multi Disc Brakes
Turning Radius With Brake- Not Specified
Steering:
Steering Type- Power Steering
Steering Adjustment- No
Power Take Off:
PTO Type- SLIPTO
PTO RPM- 540 + 540R + 540E
PTO Power- 50.3 HP
Fuel Capacity:
Fuel Tank Capacity- 66 Litres
Dimension And Weight:
Weight- 2130 kg
Wheelbase- 2145 mm
Overall Length- 3660 mm
Tractor Length- 3660 mm
Tractor Width- Not Specified
Ground Clearance- Not Specified
Lifting Capacity (Hydraulics):
Lift Capacity in Kg- 2200 kg
3 Point Linkage- ADDC (Automatic Draft and Depth Control)
Hydraulics- Fast-Response Hydraulic System
Tyre Size:
Front Size- 9.5 x 24 (8PR)
Rear Size- 16.9 x 28 (12PR)
Additional Features:
Drive Type- 4WD
Accessories- Tool, Top Link, Canopy, Hook, Bumper, Drawbar
Warranty- 2000 Hours or 2 Years
