Specifications:
Engine:
HP Category-60 HP
Engine Rated RPM-2200 RPM
No Of Cylinder-3
Air Filter- Dry Type
Cooling System-Water Cooled
Transmission (Gearbox):
Clutch Type- Dual Clutch
Transmission Type-Partial Constant Mesh
Gear Lever Position-Side Shift
Speed Minimum to Maximum-30.51 km/h (approx.)
Reverse Speed Minimum to Maximum-13.74 km/h
Forward Gears-8
Reverse Gears-2
Rear Axle-Epicyclic Reduction
Brakes:
Brake Type-Oil Immersed Brakes
Turning Radius With Brake-3400 mm (approx.)
Steering:
Steering Type-Power Steering
Steering Adjustment- No
Power Take Off:
PTO Type-Live, 6 Spline
PTO RPM-540 RPM
PTO Power-51 HP
Fuel Capacity:
Fuel Tank Capacity- 58 Litres
Dimension And Weight:
Weight- 2248 Kg
Wheelbase- 2010 mm
Overall Length- 3690 mm
Tractor Length- 3690 mm
Tractor Width-1920 mm
Ground Clearance- 420mm
Lifting Capacity (Hydraulics):
Lift Capasity In Kg-2100 Kg
3 Point Linkage-Draft, Position and Response Control Links
Hydraulics-Automatic Depth and Draft Control
Tyre Size:
Front Size-6.00 x 16
Rear Size-14.9 x 28
Additional Features:
Drive Type-2WD
Accessories-Tools, Top Link, Bumper, Ballast Weight, Canopy
Warranty-2000 Hours or 2 Years
