Eicher 480 4WD

Specifications:

Engine:
HP Category- 45 HP
Engine Rated RPM-2150 RPM
No Of Cylinder- 3
Air Filter- Dry Type
Cooling System- Water Cooled

Transmission (Gearbox):
Clutch Type-Single/Dual (Optional)
Transmission Type- Central Shift
Gear Lever Position- Side Shift
Speed Minimum to Maximum- 30.8 km/h (approx)
Reverse Speed Minimum to Maximum- 13.1 km/h (approx)
Forward Gears- 8
Reverse Gears- 2
Rear Axle- Straight Axle

Brakes:
Brake Type- Oil Immersed Disc Brakes
Turning Radius With Brake- Approx. 3.2 m

Steering:
Steering Type-Power Steering
Steering Adjustment- Not Available

Power Take Off:
PTO Type- Live, Six-spline shaft
PTO RPM- 540 RPM
PTO Power- Approx. 38.3 HP

Fuel Capacity:
Fuel Tank Capacity- 45L

Dimension And Weight:
Weight-Approx. 2055 kg
Wheelbase-Approx. 2010 mm
Overall Length-3450 mm
Tractor Length-3450 mm
Tractor Width- Approx. 1760 mm
Ground Clearance- Approx. 390 mm

Lifting Capacity (Hydraulics):
Lift Capasity In Kg- 1300 to 1400 kg
3 Point Linkage- Category II
Hydraulics- Draft, position and response control

Tyre Size:
Front Size-8.3 x 20
Rear Size-14.9 x 28

Additional Features:
Drive Type-4WD
Accessories- Tools, Top Link, Canopy, Hook, Bumper, Drawbar
Warranty- 2 years or 2000 hours (whichever earlier)
